INCONEL 925 BARS & RODS

Inconel 925 Bars, Inconel Alloy 925 Rods Supplier and Manufacturer in India


Incoloy 925 Round Bars are a highly corrosion-resistant, nickel-based alloy known for their versatility and a broad range of applications across various industries. These bars are available in two distinct types: hot-finished and cold-finished. Hot-finished bars are created by heating rods to a high temperature before drawing or extruding them into the desired shape. In contrast, cold-finished bars are produced from rods cooled to room temperature, then cut into pieces using saws or abrasive cutting tools. Both types of bars offer exceptional strength, flexibility, and corrosion resistance.

The wide-ranging applications of Incoloy 925 Round Bars stem from their outstanding strength and resistance to corrosion. These bars are widely used for pressure vessel components in the oil and gas industry and in petrochemical plant equipment, where they must withstand harsh chemicals and high temperatures. Incoloy 925 Rods are utilized in aircraft engine parts in the aerospace industry due to their ability to endure extreme temperatures and vibration stress during flight operations. They are also employed in marine structures like offshore platforms, where they must resist saltwater and other corrosive elements in seawater.

For Incoloy 925 Flat Bars, the treatment process includes ageing at 1365°F (740°C) for 8 hours, followed by furnace cooling to 1150°F (620°C), holding for 6 hours, and then air cooling. Incoloy 925 Threaded Bars offer excellent resistance to general corrosion, pitting, and crevice corrosion.

One of the main benefits of using Nickel Alloy 925 Round Bars is their superior resistance to corrosion compared to other alloys, making them suitable for extreme environments like offshore rigs or aircraft engines. They also offer an excellent strength-to-weight ratio, contributing to their lightweight construction and reducing the overall weight of structures without compromising durability or performance. These bars, such as the ASTM B425 Incoloy 925 Rods, require minimal maintenance once installed, helping to reduce operational costs over time, as they do not need frequent repairs or replacements like other materials might after prolonged exposure to harsh conditions. Furthermore, these highly durable alloys are recyclable at the end of their life cycles, allowing them to be reused rather than discarded into landfills. Incoloy Alloy Bars provide numerous advantages over conventional alloys due to their superior strength and corrosion resistance while being lightweight enough for various industrial applications. These applications include pressure vessels, petrochemical plants, aircraft engines, and marine structures like offshore rigs. Their low maintenance requirements make them cost-effective over time, as they do not require frequent repairs or replacements like other materials. Grade 925 Incoloy Round Bars can easily be recycled at the end of their life cycle, promoting environmental sustainability.

Inconel 925 Bars/Rods

Product Description

  • Type: Bars/Rods
  • Material: Inconel
  • ASTM: B805
  • Grade: 925
  • UNS: N09925
  • WERKSTOFF: -

Inconel 625 is the age hardenable alloy of iron, chromium, and nickel. The addition of alloying elements like aluminum and titanium is enabling it to become an age-hardened whereas the addition of copper and molybdenum is enhancing its several corrosive media resistance. This material is fabricated majorly for use in gas production. Also, it is made use in petroleum industries for applications like valves & tubing, well components and also in greater strength piping system. Solution annealing at the temperature ranging 1900-1800F is provided. The aging done at the temperature ranging 1350F for 8 hours and furnace cool is done at temperature 75F per hour-1175F and for about 12 hours it is kept hold at temperature 1175F and then air-cooled.

Inconel 925 BARS & RODS are having many good properties to offer like good dimensional accuracy, rugged construction, high tensile strength, and high yielding strength, smooth surface finishes, smoothness in surface finishes, long-lastingness. It too possesses general corrosion resistance, pitting-oxidation resistance, crevice corrosion & stress corrosion cracking resistance.

These rods and bars are used in several applications like offshore oil drilling industry, petrochemicals, specialty chemicals, pulp & paper industry, heat exchangers, condensers, pharmaceuticals, etc.


Incoloy Alloy 925 Round Bars Specification

Inconel 925 Round Bar manufacturer and Supplier

ASTM

ASTM B 805 / ASME SB 805

Dimensions

ASTM, ASME and API

Size

5 mm To 500 mm Dia in 100 mm TO 6000 mm Length available with NACE MR 01-75.

Length

1 To 6 Meters, Custom Cut Length

Thickness

50 mm to 6000 mm Long

Form

Round, Square, Hex(A/F), Rectangle, Billet, Ingot, Forging Etc

Types of Incoloy 925 Bar and Rods

Inconel 925 Round Bar

Incoloy 925 Round Bar

ASTM B805 Inconel Alloy 925 Round Bar, ASME SB805 Inconel 925 Rod, UNS N09925 Round Bar, Inconel 925 Round Bar, UNS N09925 Rods, Inconel 925 Rods, Nickel Alloy 925 Round Bar Exporter, Incoloy 925 Round Bar Supplier, Incoloy 925 Round Bar Manufacturer in Mumbai/India.

Inconel 925 Square Bar

Incoloy 925 Square Bar

ASTM B805 Inconel Alloy 925 Square Bar, UNS N09925 Square Bar, Inconel 925 Square Bar, ASME SB805 Incoloy 925 Square Bar, Inconel 925 Square Bar Supplier, Inconel 925 Square Rod, Nickel Alloy 925 Square Bar Exporter, UNS N09925 Square Rods, Incoloy 925 Square Bar Manufacturer in Mumbai/India.

Inconel 925 Hex Bar

Incoloy 925 Hex Bar

ASTM B805 Inconel Alloy 925 Hex Bar, UNS N09925 Hex Bar, Inconel 925 Hexagon Bar, ASME SB805 Inconel 925 Hex Bar, Incoloy 925 Hexagon Bar Supplier, Inconel 925 Hex Rod, Nickel Alloy 925 Hex Bar Exporter, UNS N09925 Hexagon Rods, Incoloy 925 Hex Bar Manufacturer in Mumbai/India.

Inconel 925 Flat Bar

Incoloy 925 Flat Bar

ASTM B805 Inconel Alloy 925 Flat Bar, UNS N09925 Flat Bar, Inconel 925 Flat Bar, ASME SB805 Inconel 925 Flat Bar, Incoloy 925 Flat Bar Supplier, Inconel 925 Flat Rod, Nickel Alloy 925 Flat Bar Exporter, UNS N09925 Flat Rods, Incoloy 925 Flat Bar Manufacturer in Mumbai/India.

Inconel 925 Forged Rod

Incoloy 925 Forged Bar

ASTM B805 Inconel Alloy 925 Forged Bar, UNS N09925 Forged Bar, Inconel 925 Forged Bar, ASME SB805 Inconel 925 Forged Bar, Inconel 925 Forged Bar Supplier, Incoloy 925 Forged Rod, Nickel Alloy 925 Forged Bar Exporter, UNS N09925 Forged Rods, Incoloy 925 Forged Bar Manufacturer in Mumbai/India.

Inconel 925 Bright Bar

Incoloy 925 Bright Bar

ASTM B805 Inconel Alloy 925 Bright Bar, UNS N09925 Bright Bar, Inconel 925 Bright Bar, ASME SB805 Inconel 925 Bright Bar, Inconel 925 Bright Bar Supplier, Incoloy 925 Bright Rod, Nickel Alloy 925 Bright Bar Exporter, UNS N09925 Bright Rods, Incoloy 925 Bright Bar Manufacturer in Mumbai/India.

Equivalent Grades of Incoloy 925 Bars and Rods

STANDARD UNS WNR.
Alloy 925 N09925 -

Incoloy 925 Bar and Rods Chemical Properties

Grade Ni% Cr% Fe% Mo% Cu% Ti% Al% Mn% Si% Nb% C% S%
Incoloy 925 42.0-46.0 19.5-22.5 Min 22 2.5-3.5 1.5-3.0 1.9-2.4 0.1-0.5 Max 1.0 Max 0.5 Max 0.5 Max 0.03 Max 0.03

Incoloy 925 Round Bar / Rods Mechanical Properties

Density Melting Point Tensile Strength Yield Strength (0.2%Offset) Elongation
8.08 g/cm3 1311°C-1366 °C 685 MPa 271 MPa 56%
